2210 Series BenchMate - Vibration-Free Platform With Passive-Air Design

上海仪舶实验室自动化 25-01-23 13:20:10

2210 Series BenchMate - Vibration-Free Platform With Passive-Air Design

The performance of precise tabletop equipment is improved with BenchMate Vibration-Free Platforms.

The Passive-Air designof the 2210 Series necessitates frequent manual leveling.

Typical Applications

Audio equipment, balances, profilometers, atomic force microscopes,microhardness testers, and other precision measuring and testing instrumentation.

2210 Series BenchMate - Vibration-Free Platform with Passive-Air Design

Image Credit: Kinetic Systems, Inc.

Features and Benefits

Unparalleled price/performance

Vibra-dampened structure

Low-profile, Passive-Air design

Low inherent frequency

Flatness: ±0.004 ” over 24×24 ” on top surfaces -22 and -32

Compatible with Class 100 cleanrooms– Class 10 available

SPILLPRUF spill management

Specifications

Performance Data. Source: Kinetic Systems, Inc.

Min. Load @ 20 psi
Vertical Natural Frequency 2.3 Hz
Isolation Efficiency @ 5 Hz 52 %
Isolation Efficiency @ 10 Hz 83 %
Horizontal Natural Frequency 2.9 Hz
Isolation Efficiency @ 5 Hz 40 %
Isolation Efficiency @ 10 Hz 92 %
Max. Load @ 80 psi
Vertical Natural Frequency 2.1 Hz
Isolation Efficiency @ 5 Hz 70 %
Isolation Efficiency @ 10 Hz 91 %
Horizontal Natural Frequency 1.8 Hz
Isolation Efficiency @ 5 Hz 81 %
Isolation Efficiency @ 10 Hz 95 %
Net Load Capacity @ 80 psi
200 lbs. (91 kg)
Finish
Standard Linear WhitePolyurethane
Class 10 White EpoxyPowder Coat
Approximate Shipping Weight
2210-01-xx 157 lbs. (72 kg)
2210-04-xx 145 lbs. (66 kg)

Note: Typical performance efficiencies are for microdisturbances.

2210 Series BenchMate - Vibration-Free Platform with Passive-Air Design

Image Credit: Kinetic Systems, Inc.

2210 Series BenchMate - Vibration-Free Platform with Passive-Air Design

Image Credit: Kinetic Systems, Inc.

Configuration

2210 Series BenchMate - Vibration-Free Platform with Passive-Air Design

Image Credit: Kinetic Systems, Inc.
