XYZ Positioning Stage System for Fiber Alignment and Photonics Alignment - F-131 from PI

The high-precision coarse/fine XYZ stages are computer-controllable, compact XYZ alignment and positioning systems that integrate the benefits of ultra-high-resolution piezo drives with the long travel range of motorized stages. Eight versions are available having stepper- and DC-motor coarse drives, and open- and closed-loop piezoelectric fine drives. A high-performance controller for automated XYZ photonic component alignment is also available.

Salient Features

The salient features of the F-131 PI are:

It is a high-speed coarse or fine alignment solution.

It is equipped with a high-performances controller for automated alignment.

Complete device characterization in less that 1 s.

Closed-loop servo-motors and stepper motors are available.

It has a positioning range up to 15 mm in XYZ.

It has 1-nm resolution.

100x100x100 μm piezo fine resolution

Optional closed-loop piezo is available.

Fast Multi-channel Photonics Alignment Engine / Silicon Photonics Test Platform www.pi.wsPlay
