XRF Spectrometer ARL OPTIM’X from Thermo Scientific

For the elemental analysis of solids and liquids, the wavelength dispersive X-Ray fluorescence (WDXRF) method is a very adaptable analytical approach. With great accuracy, precision, and dependability, a variety of samples including elements from beryllium to uraniummay be examined.

Salient Features

The following are the notable features of the ARL OPTIM’X:

No gas supply is needed

Direct and simple introduction of the sample

Unique compact SmartGonio for sequential analysis

Sequential-simultaneous configuration blending speed with analytical flexibility

High accuracy, both short-term and long-term repeatability due to temperature regulation of spectrometer and crystals

Superior spectral resolution from low atomic number elements to heavy elements (~15 eV at CaKa)

Optimum configuration for specific applications with simplified operation, which is compliant with ISO and ASTM standards

Stand-alone and autonomous operation without the need for water cooling

Automatic analysis of batches with sample changer

Small footprint

Innovative WDXRF platform with simultaneous and/or sequential capabilities

Element coverage from fluorine to uranium, based on the configuration

Innovative Ultra Closely Coupled Optics (UCCO) technology for increased intensity, up to 210% more than conventional geometry

Multichromators for rapid analysis

The following elements of the ARL OPTIM’X can be customized for speed and flexibility:

50 W basic or 200 W optional power to achieve 2.5 times faster analysis

Sequential-simultaneous analysis: SmartGonio and 2 elements simultaneously on one multichromator

Up to 8 elements simultaneously using 4 multichromators

Sequential analysis with the SmartGonio

Applications

The ARL OPTIM’X may be set up for a variety of uses, such as:

Food industry for major and minor nutrients and other regulated elements

Major and minor oxides in products such as sanitary ceramics, refractories, slags and sinters

Glass, paints, paper, ferro-alloys, silicon, metal sheets and other products where a few major and minor elements need to be monitored

Major and minor oxides in raw materials such as limestone, sand, feldspar, bauxite, magnesite and other mining applications

Petroleum industry: The analysis of S (ISO 14596 or ASTM D2622), Pb (ASTM D5059) or other elements in gasoline, fuels and oils
