The T Series of TO-Can Laser Packages from Sheaumann
T Series TO-Can packages from Sheaumann provide users with continuous-wave, high power, single-modeand multimode options on industry-standard submounts.
The packages are hermetically sealed with AR-coated windows and also with a photodiode (optional). The proprietary laser chip design from Sheaumann provides unmatched quality and an extended lifetime. The wavelength emission range is 780 to 1070 nm with narrow tolerance options.
Wavelength Emission Range is 780–1070 nm
5.6 mm. Image Credit:Sheaumann Laser, Inc.
Table 1. Source: Sheaumann Laser, Inc.
| Category | Specifications |
|---|---|
| Dimensions (Length x Diameter) | 10 mm x 5.6 mm |
| Single-mode Power | 50 mW - 80 mW |
| Multimode Power | 200 mW - 500 mW |
| Wavelength Tolerance | +/- 3,5,10 options |
| Photodiode | Optional common anode (+) or cathode (-) |
| Cap | Taped/loose, or welded |
| Chip Mount | p-up or p-down (Single-mode only) |
9 mm. Image Credit:Sheaumann Laser, Inc.
Table 2. Source: Sheaumann Laser, Inc.
| Category | Specifications |
|---|---|
| Dimensions (Length x Diameter) | 11.5 mm x 9 mm |
| Single-mode Power | 50 mW - 300 mW |
| Multimode Power | 50 mW - 500 mW |
| Wavelength Tolerance | +/- 3,5,10 options |
| Photodiode | Optional common anode (+) or cathode (-) |
| Cap | Taped/loose, or welded |
| Chip Mount | p-up or p-down (Single-mode only) |
| Fast Axis Microlensing | Optional, square beam or collimated <2% |
9 mm Tall. Image Credit:Sheaumann Laser, Inc.
Table 3. Source: Sheaumann Laser, Inc.
| Category | Specifications |
|---|---|
| Dimensions (Length x Diameter) | 9mm x |
| Single-mode Power | up to 600 mW |
| Multimode Power | up to 3 W |
| Wavelength Tolerance | +/- 3,5,10 options |
| Photodiode | Optional common anode (+) or cathode (-) |
| Cap | Taped/loose, or welded |
| Chip Mount | p-up or p-down (Single-mode only) |
| Fast Axis Microlensing | Optional, square beam or collimated <2% |
