The BeDensi T Pro Series: A Tapped Density Meter

The BeDensi T Pro Series from Bettersize is a dependable tapped density tester that stands out when it comes to intuitive operation. The instrument complies with the ASTM, European Pharmacopeia (EP2.9.34), ISOand United States Pharmacopeia (USP<616>).

It has the ability to quantify the tapped density and bulk density with 1.0% repeatability to help users comprehend the flowability of an extensive range of powder materials.

This tapped density tester includes the main body, graduated cylinders, control paneland embedded mini printer. The tapping frequency and numbers can be adjusted. Moreover, the cylinder types (25, 100or 250 mL) and drop height (3 or 14 mm) are also available based on various requirements.

The BeDensi T Pro Series is the perfect tester to identify the tapped density of various types of powders in different industries like food and beverage, pharmaceuticals, chemistry, metallic powders and compounds, carbon and ceramicsand batteries.

BeDensi T Pro Series | Tapped Density Tester with a Wallet-Friendly SolutionPlay

Video Credit: Bettersize Instruments Ltd.

Benefits

Compliance

The BeDensi T Pro Series fulfills the ASTM, EP, ISOand USP standards to offer informative outcomes.

Easy to Use

Users can easily set measurement conditions with the help of a membrane keypad

Users can just click to print detailed reports

Cylinders can be replaced rapidly with the simple lock holders

Wallet-Friendly

Users can own a dependable tapped density tester at a reasonable price.

Up to Three Workstations

The single tapped density tester comes with up to three workstations to fulfill various measurement requirements and scale up users’ productivity even more.

Image Credit: Bettersize Instruments Ltd.

Compliance

The BeDensi T Pro Series fulfill the standards of various industries by supporting 25, 100and 250 mL cylinders; 3 or 14 mm drop height; and a speed of 100–300 taps/minute.

ASTM

Drop height of 3 or 14 mm and speed of 100–300 taps/minute

Cylinder: 25, 100or 250 mL

ISO

Drop height of 3 or 14 mm and speed of 250 or 300 taps/minute

Cylinder: 250 or 100 mL

USP and EP Methods Ⅰ

Drop height of 3 mm and speed of 250 taps/minute

Cylinder: 25, 100, 250 mL

USP and EP Methods Ⅱ

Drop height of 3 mm and speed of 100–300 taps/minute

Cylinder: 25, 100or 250 mL

User-defined

Drop height of 3 mm and speed of 250 taps/minute

Cylinder: 250 or 100 mL

Applications

Batteries

Chemistry

Carbon

Food and beverage

Ceramics

Pharmaceutical

Metal powder and compounds

The BeDensi T1 Pro is easy to use and has an intuitive keyboard for setting various measurement conditions. The report can be printed out immediately after each measurement. Most importantly, the noise level of this device has been significantly reduced compared to the previous version.

K-ONE, South Korea

Standardized Measurement Procedure

1. Selecting the Cylinder Size

Depending on the density and types of samples, a proper cylinder size must be chosen (25 mL, 100 mLand 250 mL optional)

Users should place the cylinder on the supporter and lock it with the holder

2. Setting the Test Conditions

The number of taps and the speed should be entered

Speed: 100–300 taps/minute

Number of taps: 1 to 99,999

For example, the number of taps is 10, 500and 1250, and the speed is 250 taps/minute (3 mm drop height), according to USP and EP.

3. Weighing the Sample

Users should filter the sample using a 1.0-mm sieve. Samples should be weighed in grams and poured into the cylinder gently.

Then, the test can start.

4. Reading the Volume

A mean tapped volume value can be achieved from three readings.

5. Printing the Report

Users only have to input the weight and the tapped volume while the BeDensi T Pro Series automatically estimates the tapped density and prints the report when the print button is pressed.

The outcomes can be utilized to evaluate the Hausner Ratio (HR) and the Compressibility Index (CI) and additionally calculate the flowability of samples.

Performance



Image Credit: Bettersize Instruments Ltd.

The image above shows 10 cycle measurements of two samples, indicating the high repeatability (<1.0%) of the BeDensi T Pro Series. Intricate and standardized design enables the tapped density tester to offer informative and reliable results.



BeDensi T3 Pro with 3 Workstations.Image Credit: Bettersize Instruments Ltd.

Accessories

Graduated Glass Cylinder



25 mL Cylinder. Bettersize Instruments Ltd.



100 mL Cylinder. Bettersize Instruments Ltd.



250 mL Cylinder. Bettersize Instruments Ltd.

Supporter and Holder



Holder. Bettersize Instruments Ltd.



3 mm Supporter. Bettersize Instruments Ltd.



14 mm Supporter. Bettersize Instruments Ltd.

Specification

Source: Bettersize Instruments Ltd.

.	.	.
Test Workstation	Up to 3
Compliance	USP <616>,
	EP 2.9.34,
	ASTM D7481
	ASTM B527
	ISO 787-11
	User defined
Taps	1 to 99999
Speed	100 to 300 taps/min (adjustable)
Drop Height	3 ± 0.2 mm	For nominally 250 ± 15 taps/min
	14 ± 2 mm	For nominally 300 ± 15 taps/min
Graduated Cylinder	25 ml	Readable to 0.2 ml
	100 ml	Readable to 1 ml
	250 ml	Readable to 2 ml
Repeatability	≤1%
Power	100-240 VAC/50-60 Hz/ 50 W
Dimensions	Width	260 mm
	Depth	410 mm
	Height	245 mm
Weight	T1	16 kg
	T2	18.2 kg
	T3	21 kg

The BeDensi T3 Pro has a very good compact design and is easy to use. The automatic data analysis not only saves the costs of manual calculation, but also provides us with a stable and informative result. Bettersize instruments play an important role in the development of our products and we will continue to purchase BeDensi T3 Pro in the future.

Heilongjiang Pride New Material Technology Co., Ltd
