TeachAide™ Workstation for Ductless Classroom Engagement
During popular chemical experiments, AirClean® Systems TeachAide ductless classroom demonstration workstations offer a low-cost, safe option to protect students, teachers, and the environment.
Image Credit: Synoptics Ltd
Protection from experiments producing harmful fumes, vapors, particulate matter, or smoke is ensured by bonded carbon and HEPA filters, a robust thermoplastic construction, and the AirSafe™automated safety controller. A classroom with true 360° visibility encourages full participation.
Image Credit: Synoptics Ltd
Features
AirSafe automated safety regulator
Integrated base featuring a deep spill lip
No ductwork is necessary
Plugs straight into a conventional 110 V or 220 V electrical outlet; no installation is necessary
An opaque polycarbonate exterior enabling complete visibility
Very quiet operation (less than 49 dBA)
Event timer for the lab
HEPA filtration to collect particles as small as 0.3 µm
Gas phase bonded carbon filtration
Benefits
To guarantee proper filter replacement, use the filter safety lockout
Flammability-resistant prefilter
Completely assembled upon shipment
Certified to CSA C22.2 No. 61010-1, EN 61326-1, and UL 61010-1 standards
Brushless, sparkless blower is post-filter
Accidental leaks are adequately contained by deep base
As the filter and electronics are situated above the workspace, there is little possibility that a chemical spill will reach these delicate locations
The low airflow alarm alerts the user vocally and graphically
Monitoring the installed filtration bed in real-time
Options
Robust trolley/cart with casters that lock for ease of mobility
Dimensions
Source: Synoptics Ltd
inches
| Product # | External | ||
|---|---|---|---|
| Width | Depth | Height | |
| ACTA32 | 32" | 25" | 40" |
| ACTA48 | 48" | 25" | 40" |
| Product # | Internal | ||
| ACTA32 | 31" | 23" | 25" |
| ACTA48 | 47" | 23" | 25" |
Source: Synoptics Ltd
mm
| Product # | External | ||
|---|---|---|---|
| Width | Depth | Height | |
| ACTA32 | 813 mm | 610 mm | 762 mm |
| ACTA48 | 1219 mm | 610 mm | 1016 mm |
| Product # | Internal | ||
| ACTA32 | 787 mm | 584 mm | 508 mm |
| ACTA48 | 1194 mm | 584 mm | 635 mm |
Functionality
How it Works
A: Room air flows away from the operator and enters the enclosure horizontally.
B: The air mixes with gases and vapors.
C: The contaminated air is directed through the filtration bed.
D: Clean air is recirculated into the room.
Image Credit:Synoptics Ltd
