Syringe Particle Sampler SLS-20
The SLS-20 Syringe Liquid Sampler allows Chem 20™ or Chem 20-HI particle counters to work in batch sampling applications. It is ideal for precise, small-volume sampling.
The system consists of an SLS-20 for corrosive or non-corrosive liquids. It is also complete with all essential connections for integrationwith a compatible Chem 20 or Chem 20-HI particle counter and includes optional software.
Benefits
Menu-driven data collection
Exceptionally precise measurements
Works with both non-corrosive and corrosive liquids
20 nm sensitivity provides an unmatched level of process, chemical, and filter monitoring
Fluoropolymer syringe standard for use with hydrogen fluoride (HF)
Minimal chemical volume used
Completely automated system
Features
Software for data collection and trending
Optional password security
Data generation into pre-formatted report formats and spreadsheets using SamplerSight software
Internal leak detection
Repeatable recipes for consistent sampling parameters
Applications
Extracting chemicals from the packaging of finished products
Extracting samples from wet process tanks to monitor the process and filters
Small volume chemical quality assurance
Parts cleanliness testing
Laboratory water sampling
Industries: semiconductor, pharmaceutical, data storage, medical, aerospace, automotive
Specifications
Source: Particle Measuring Systems
| . | . |
|---|---|
| Syringe size | 50 ml (standard), 25 ml (optional) |
| Sampling mode | Vacuum, Batch |
| Wetted surface materials | Kel-F®, PFA, PTFE, Kalrez® |
| Sample volume | Adjustable with software interface |
| Sample temperature | 59 – 104 °F (15 – 40 °C) |
| Dimensions (l x w x h) | 10.0 x 9.0 x 12.3 in (25.4 x 22.9 x 31.2 cm), not including particle counter |
| Weight | 14 lb (6.4 kg), not including particle counter |
| Power | 100 – 240 V, 50 – 60 Hz |
| Environment | Temperature: 50 – 86 °F (10 – 30 °C)Humidity: Non-condensing |
Image Credit: Particle Measuring Systems
