Series LSMA-175-XYZ Compact Motorized Multi-Axis Systems from IntelLiDrives

Integrated multi-axes XYZ systems built with LSMA-175 Series motorized actuators provide travel up to 200 mm. Driven by a brushless or stepper motor with a precision ground ball screw this motorized stages offers high-resolution up to 0.1 micron. Actuator has low profile high-stability compact and monolithic design as its main feature and together with its high resolution makes the device ideal for its integration in high precision measurement and manufacturing systems.

Specifications

Travel area up to 200 x 200 x 200 mm

Resolution 0.1 micron

Load capacity 8 kg

Straightness 5 microns
