Precise Density and Sound Velocity Measurement with DMA 5001 Sound Velocity

DMA 5001 Sound Velocity is the ideal tool for rapid concentration determination. It offers unmatched accuracy and efficiency by seamlessly combining density and sound velocity measurements.

Quality controland research and developmentdepartments in numerous industries can use it to improve productivity and streamline processes. Its automatic concentration determinationreduces the need for human intervention by maximizing efficiency.

Discover the future of analysis—the density and sound velocity meter DMA5001 Sound Velocityis the only device witha single setup to measure sulfuric acid concentration over the whole range.

A single device that measures both density and sound velocity

Establishes the concentration of solutions with two and three components

Industry-specific profile“Chemicals”

Benefit from 40 years of application experience

Successor to the DSA 5000 M

Key Features

Density and Sound Velocity Measurement Combined in Just One Instrument

Image Credit: Anton Paar GmbH

The superior DMA 5001 Sound Velocity, the only instrument that combines the two measurement technologies in a single setup, is the result of the company’s more than four decades as the market leader in density and sound velocity measurement. Thanks to the repeatability of up to 0.1 m/s for sound velocity and up to 1 *10^–6 g/cm³ for density, users can obtain high-precision results in less than three minutes.

Modularity Enables Multiparameter Analysis

Image Credit: Anton Paar GmbH

With sophisticated multiparameter measurement systems, which can measure more than 10 parameters in a single cycle from a single sample, users can extract the most information possible from the sample with unmatched efficiency and accuracy.

The DMA 5001 Sound Velocity offers unparalleled precision, repeatability, and reproducibility, especially when measuring binary and ternary solutions and figuring out the sugar inversion process. By integrating different filling systems (Xsample sample changer family) users can measure 20+ samples per hour for high sample throughput.

Additional modules, including turbidity, pH value, refractive index, and concentrations of CO₂ and O₂, allow users to extract even more information.

Benefit From More Than Four Decades of Application Experience

Image Credit: Anton Paar GmbH

The DMA 5001 Sound Velocity is well-suited for various industries, including the beverage industry (such as soft drinks) and chemical production (such as sulfuric acid), thanks to more than 30 methods and four decades of application experience. Many pre-defined tableshave been integrated, including acid/base tables, which are crucial for figuring out the concentration of binary and ternary mixtures.

The DMA 5001 Sound Velocity’s accuracy and adaptability make it a vital tool for ensuring quality and uniformity across numerousproduction processes.

The Most Stable Results Available

Image Credit: Anton Paar GmbH

Relyon features such as ThermoBalance^TM, the U-View^TMcamera, viscosity correction, and Filling Check^TMto ensure all analysesmaintain100% accuracy and traceability.

FillingCheck^TMquickly identifies any filling errors and, if necessary, issues a warning by identifying gas bubbles or other particles in the sample.

The U-View^TMcamera provides live images of the filled U-tube for continuous monitoring.

Viscosity correction successfully removes viscosity-related errors throughout the samples’ whole viscosity range, ensuring high repeatability of density results. ThermoBalance^TMprovides precise results directly uponchanges in measurement temperature.

Global Support, Local Assistance: Peace of Mind with Anton Paar Certified Service

Image Credit: Anton Paar GmbH

Take advantage of the vast global network of more than 35 subsidiaries and 85 service partners worldwide, which guarantees users receive local support in their preferred language and in the shortest amount of time.

The investment is protected throughout its lifecycle with Anton Paar Certified Service, supported by more than 350 manufacturer-certified technical experts globally. Benefit fromthe extra assurance of a three-year warranty, which ensures reliability and longevity.

Technical Specifications

Source: Anton Paar GmbH
