PI M-403 Low Cost Precision Linear Stages

The M-403 and M-404 linear translation stage series provide cost-effective solutions for precision positioning of loads up to 20 kg over travel ranges to 200 mm. They are designed with high-value components and feature a precision-machined, high-density, stress-relieved aluminum base for exceptional stability with minimum weight.

The highly precise M-403 drive includes a preloaded lead screw, providing a minimum incremental motion of 0.2 µm. For higher velocities and long lifetime, the M-404 versions feature a low-friction ball screw offering a minimum incremental motion down to 0.1 µm.

Three motor drive options allow easy adaptation to different automation applications. Five travel ranges from 25 to 200 mm are offered. The stages can carry up to 20 kg and push/pull up to 50 N. Special versions for vacuum applications are also available.

Features & Advantages

For Cost-Sensitive Precision Positioning Applications

Travel Ranges 25 to 200 mm

Resolution to 0.012 µm

Min. Incremental Motion to 0.1 µm

Preloaded Precision Leadscrew or Recirculating Ball Screw Drives Provide High Speeds & Long Lifetimes

Stress-Relieved Aluminum Base for Highest Stability

Vacuum-Compatible Versions Available

M-413 and M-414 Versions for Higher Load Requirements

Application Examples

Automation

R&D

Semiconductor technology

Metrology

Quality assurance testing
