PEM Hydrogen Generators: 0.27 to 1.05 Nm³/h
S Series electrolysers use Proton Exchange Membrane (PEM) technology to produce high purity hydrogen of 99.999+% at up to 1.05 Nm3/h. They replace the need for pressurized hydrogen cylinders in a variety of industrial processes. The units are low maintenance, compact, quiet, and typically can be installed within hours virtually anywhere in a facility.
Features
Pure hydrogen at process pressure – up to 30 barg (435 psig) hydrogen and 99.9995% purity
Specifications
Source: Nel Hydrogen
| Specifications | S10 | S20 | S40 |
|---|---|---|---|
| Nominal Production Rate | 0.27 Nm3/h (10 SCF/H)0.58 kg/24h | 0.53 Nm3/h (20 SCF/h)1.14 kg/24 h) | 1.05 Nm3/h 40 SCF/h)2.27 kg/24h |
| Turndown Range | 0 to 100% | 0 to 100% | 0 to 100% |
| Power Consumption by System at 100% Capacity1 | 6.1 kWh/Nm3(16.3 kWh/100 SCF) | 6.1 kWh/Nm3(16.3 kWh/100 SCF) | 6.1 kWh/Nm3(16.3 kWh/100 SCF) |
| Purity | 99.999+% | 99.999+% | 99.999+% |
| O2-Content in H2 | < 1 ppm v | < 1 ppm v | < 1 ppm v |
| H2O-Content in H2 | < 5 ppm v | < 5 ppm v | < 5 ppm v |
| Delivery Pressure | 13.8 barg(200 psig) | 13.8 barg(200 psig) | 13.8 barg(200 psig) |
| Dimensions – L x W x H | 0.8 m x 1 m x 1.1 m(2.6 ft x 3.3 ft x 3.6 ft) | 0.8 m x 1 m x 1.1 m(2.6 ft x 3.3 ft x 3.6 ft) | 0.8 m x 1 m x 1.1 m(2.6 ft x 3.3 ft x 3.6 ft) |
| Ambient Temperature | 5 to 40º C (41 to 104º F);Optional5 to 50º C(41 to 122º F) | 5 to 40°C(41 to 104º F) | 5 to 40°C(41 to 104º F) |
| Electrolyte | Proton Exchange Membrane | Proton Exchange Membrane | Proton Exchange Membrane |
| Feed Water Consumption | 0.9 l/Nm3 | 0.9 l/Nm3 | 0.9 l/Nm3 |
For reference only – specifications are subject to change. Please contact Nel Hydrogen for solutions to best fit your needs.
1Beginning of life and dependent on configuration and operating conditions.
