Optical Coordinate Measuring System: Maxshot 3D

Creaform’s MaxSHOT 3D lineup is a game changer for product development, manufacturing, quality control and inspection teams that need the highest measurement accuracy and repeatability as much for large‑scale projects than for parts from 2 to 10 m. Imagine achieving accuracy better than 0.015mm/m!

Thanks to its sophisticated user guidance technology and easy‑to‑use software, the MaxSHOT 3D is ideal for users of all levels—even non‑metrology experts—so that you gain peace of mind knowing your measurements are always right on the dot and you increase process efficiency.

If you consistently work on large‑scale projects, the MaxSHOT 3D is your go-to solution to slash budget-busting measurement mistakes, improve product quality, increase process efficiency—and minimize overall operating costs.

Features

Automatic feedback on measurement quality: Laser projected frame with GO/NO-GO feedback on measurement pictures

Unrivaled accuracy: 40% more accurate on parts with size ranging between 2 m and 10 m

Maximized user comfort: 50% lighter compared to traditional photogrammetric devices

More dependable than a mere traditional camera: Engineered especially for photogrammetric applications

Applications

The MaxSHOT 3D provides 3D measurements directly or work readily with Creaform’s other technologies to perform 3D measurements on large components.

Inspection and quality control

First article and supplier quality inspection

Alignment

Part-to-CAD analysis

Conformity assessment of large factory-made parts against the originals

Conformity assessment of 3D models against original large parts/production tooling

Complete free-form inspection and high‑density color maps when used with a 3D scanner

Tooling certification

Reverse Engineering

Faster and more accurate reverse engineering of large mixed parts (geometrical and free-form) when used with 3D scanner

Reverse engineering of geometrical entities (cylinders, spheres, planes)

Industries

Consumer products

Heavy industries

Aerospace

Power generation

Automotive/transport

Research and education

Manufacturing

Measuring Large-Scale Metrology Projects
