Nova: Surface Pore and Area Analyzer

The Nova series from Anton has been specifically developed to offer operational simplicity and velocity – speed in the unwavering direction of accuracy – throughout the complete analysis process.

The DSA 5000 M consists of four degassing stations and also up to four analysis stations, and thus provides four 5-point BETs in 20 mins, with 2% reproducibility. Users can follow the analysis workflow to learn how Nova offers peerless advantages right from start to finish and sets a new standard in surface area and pore characterization.

600 BET

Quickest multi-station BET analyzer available for entry-level budgets

All-in-one instrument: Four degassing and two analysis stations

Improved short cells and Dewar for BET analysis with less waste

User-friendly with pre-loaded profiles and a 10″ touchscreen

Reproducibility of 2% with ≥2 m² complete measurement surface area

800 BET

Availability of highest-throughput BET surface area analyzer

All-in-one instrument: Four analysis and four degassing stations

Four samples available for five-point BETs in just 20 minutes

User-friendly with pre-loaded profiles and a 10″ touchscreen

Reproducibility is 2% with ≥2 m² complete measurement surface area

600

Availability of BET surface area, pore sizeand pore volume analyzer

All-in-one instrument: Two analysis and four degassing stations

2 BETs performed in 15 minutes, two isotherms in 6 hours

Reproducibility is 2% with ≥2 m² total measurement surface area

User-friendly with pre-loaded profiles and a 10″ touchscreen

800

Greatest-throughput BET surface area, pore sizeand volume analyzer

Four BETs in just 20 minutes, four isotherms in 8 hours

All-in-one instrument: Four analysis and four degassing stations

User-friendly with pre-loaded profiles and a 10″ touchscreen

Reproducibility is 2% with ≥2 m² complete measurement surface area

Benefits

Sample Preparation

All-in-One

The entire packing is available in one space-saving design

Degassing isolated from the analysis: no contamination possible

Just one vacuum pump and one set of gas connections are required

Programmable

Degassing is entirely automated. Users can just choose a profile

No need for timers or operator intervention

Users can set up multiple temperature set points and ramp rates

Fully Capable

Vacuum or flow degassing ranges up to 425 °C

Users can shift easily between flow and vacuum methods

Allows preparation of an extensive range of sample materials

Traceable

Manual input or recording is not required

Degassing profile tracked automatically to the sample ID

Sample ID tracks weight loss following degassing

Method Selection

20+ Profiles

Decreases setup time of instrument

Improved speed while guaranteeing conformance

ISO, ASTM, USP, ISO techniques included — users can just select and go

Analysis Velocity

Power of 4 + 4

Users can examine four samples while concurrently making the next four

Highest throughput available in a benchtop system

Four multipoint BETs in just 20 minutes; four isotherms in 8 hours

TruZone

TruZone improves analysis sensitivity

2% reproducibility with >2 m² in the cell

Quantify materials down to 0.01 m² /g.

Nova Mode

Users can make use of Nova mode to achieve their results quicker

4 × 5-point BET outcomes in just 20 minutes

Users can operate their Nova completely free of helium

Intelligent Dosing

DoseWizard learns from past analyses to improve dose size

Users can achieve target pressure rapidly with a particular initial fill

VectorDose’s constant dose volumes halve analysis time

P₀ Cell

A separate station constantly quantifies saturation pressure

It is standard on every Nova model — no need for options

It is complete with a steadfast pressure transducer

Results Reporting

In Real-Time

Envision the outcomes in real-time on the touchscreen

Users can completely control the instrument from the touchscreen

Previous results can be uploaded directly on the touchscreen

Templates

20+ included report templates for industry standards

Users can configure reports for automatic creation following analysis

Completely customizable reporting

Data Reduction

Proprietary QSDFT kernels available for carbon characterization

25+ peer-reviewed DFT kernels

Identify BET range for microporous materials in an automatic manner

Technical Specifications

Source: Anton Paar GmbH

*Includes precision, linearity, and hysteresis s of the complete pressure measurement system

**Performed with BAM P115 certified reference material
