Non-Glass Flat Panel Detector
This incredibly durable, non-glass flat panel detector, also known as a digital detector array (DDA), was made from the ground up with field radiography's demanding conditions and optimum portability in mind.
High contrast
GOS scintillator with high sensitivity.
Large format
36×43 cm active area is ideal for profile images.
Portable and Ruggedized
6.6 kg/1 m drop test pass.
Important Features
Image Credit: DÜRR NDT GmbH & Co. KG
140 μm pixel pitch (3.6 LP/mm).
Suitable for X-Ray and gamma sources.
Electronics insulated for use at up to 350 kV.
Extremely durable non-glass detector.
The hot-swap capability allows for battery changes while the device is in use.
Two screw-on WLAN antennas offer a long-range and stableconnection.
Gigabit Ethernet and power connectors.
Dust-tight and waterproof (IP67).
Passes 1-meter drop test.
Technical Data
Source: DÜRR NDT GmbH & Co. KG
| DRC 3643 NDT | |
|---|---|
| Active area | 430 mm x 358 mm (16.9" x 14.1") |
| Dimensions(H x W x D) | 439 mm x 465 mm x 20 mm |
| Weight | 6.6 kg (14.5 lbs) |
| Number of pixels | 3072 x 2560 |
| Exposure time | 0.5 s to 180 s |
| Image transfer time(wired/wireless) | 0.7 s / 1.8 s |
| Max. energy | 350 kV (for long life in typical applications), Isotopes (higher energies possible) |
| Pixel pitch | 140 μm |
| Scintillator | GOS |
| ADC | 16-bit |
| Interface | Gigabit Ethernet, WLAN: 2.4 GHz SISO 802.11n/5GHz MIMO (2T2R) 802.11ac |
| Battery | Lithium-ion (7.4 V, 4000 mAh) |
| Operating conditions | 0 to 45 °C (32 to 113 °F), 30 to 85 % humidity |
| Protection level | IP67 (dust-tight and waterproof) |
| Housing | Aluminum frame, carbon-fiber entrance window |
| Software | DÜRR NDT D-Tect X |
| Scope of supply | Detector, 2 batteries, battery charger, Ethernet and power adapter cable |
Sample Images
With the Advanced Wall Thickness Tool of D-Tect X, you can easily analyze the wall thickness of a pipe. Image Credit: DÜRR NDT GmbH & Co. KG
Aluminum casting, t = 10 mm, shrinkage cavity. Image Credit: DÜRR NDT GmbH & Co. KG
Aluminum casting, t = 10 mm, shrinkage cavity. Image Credit: DÜRR NDT GmbH & Co. KG
Carbon steel, t = 9.6 mm, weld seam defects. Image Credit: DÜRR NDT GmbH & Co. KG
