MX-Lab: Material Research & Alloying Machine
MX Lab provides high-precision metal 3D printing solutions tailored for research and prototyping applications.
Download the Brochure for More Information
Basic Additive Manufacturing system
Entry-level Direct Energy Deposition (DED) AM machine
Three-axis system with DMT® technology
Superior fiber laser system
Specialized for Research Purposes
Prototyping and material research
New alloys can be developed
Six powder feeders with accurate feeding rate control
Remarkable User Experience
Multi-materials Slicer software program
Simple touchscreen operation
Affordable and user-friendly system
CVM Feeder Specification
Next Step of Powder Feeding System
The CVM (Clogged Vibration Method) powder feeder is an advanced and sophisticated type of powder feeding system.
It has a wide range of feeding rates, a semi-permanent lifespan, and an exceptionally stable powder feed rate. Without changing the hardware, it can feed titanium powder at rates ranging from 0.03 g/minute to 2 g/minute. Additionally,direct powder supply method with gas and the gravity powder supply method can both be used in theDED process.
Image Credit: InssTek, Inc.
Image Credit: InssTek, Inc.
Download the Brochure for More Information
Second Generation AM Module
Creative Additive Manufacturing Machine in DMT® Technology
Second Generation AM Module
Suitable for Shielding gas during deposition
Optimized design for 400 µm beam diameter
Activate DMT® mode with the vision system
Active Powder Splitter
Co-Axial Powder Splitter
The powder can be distributed evenly in small amounts.
Powder feeding without mechanical adjustment or calibration
Image Credit: InssTek, Inc.
Download the Brochure for More Information
Technical Data
MX-Lab Specification
Source:InssTek, Inc.
| Laser | MX-Lab | |
|---|---|---|
| Туре | Ytterbium Fiber Laser | |
| *Laser Power | W | 300 (*Max. 500) |
| Safety Standard | EN60825-1 | |
| Stage | ||
| X, Y, Z Stroke | mm | 150 x 150 x 150 |
| A, C Stroke | deg. | N/A |
| Worktable Size | mm | 175 x 175 |
| Module | ||
| *Optical Module | SDM 400 | |
| Beam Diameter | μm | 400 |
| Build Rate | cm3/hour | 1.5 ± 0.2 |
| Layer Thickness | μm | 150 + 50 |
| Feeding System | ||
| Powder Feeding Rate (for Ti-6Al-4V) | g/minute | 0.03~2 |
| Powder Hopper Volume | liter | Approx. 0.42 |
| *Number of Powder Feeder and Hopper | set | 6 |
| Software | ||
| Operating System | MX-Lab OS | |
| *CAM Software | MiXOMaterial Designer | |
| Feedback System | DMTR®Closed-Loop Control | |
| Electrical Specification | ||
| Electrical Power Type | Hz | 1P + PE (at 50/60) |
| Main Machine Voltage | V | 220 |
| Full Load Current | A | 15 (20) |
| Mechanical Specification | ||
| Machine Dimensions (without accessories) | mm | 680 x 684 x 835685 x 775 x 835 |
| Machine Weight | kg | 250 (*Max 350) |
(*Optional Item)
[MX-Lab: Material Research & Alloying Machine]相关推荐
170 PRO C Diamond Core Drilling Rigs from ROTHENBERGER
In order to lay to pipes in walls made of concrete reinforced concrete, natural or artificial sto……...
AIRsight™ Infrared/Raman Microscope
The AIRsight™ Infrared/Raman Microscope from Shimadzu Scientific Instruments offers a two-i……...
Golden Chalice Resources Limited
Golden Chalice is well positioned to discover and capitalize on world class gold, silver, copper,……...
Measuring Gasoline, Crude Oil, and Jet Fuel with the MiniVap VP/VPL Vision
MINIVAP VP Vision is a portable, highly multifaceted vapor pressure tester with a pressure range ……...
Dahua Technology USA
Dahua North America combines stellar customer service with unparalleled technology to create high……...
今日仪器
-
Applegate Marketplace Ltd.
Applegate is the UK's best known and longest established internet directory for industry, manufacturing and technology in the UK and Ireland. It is the largest and most comprehensive directory……
-
Dynamic Characterization of Encapsulated MEMS
