Measuring Industrial Application with the Laser Level Transmitter LLT100

The LLT100 is a high-performance laser transmitter that is capable of accurately measuring the level, distance, and position of a sample in a consistent manner over both short and long ranges.

This non-contact level measuring instrument has been specifically designed for evaluating process automation and inventory management in a wide variety of industrial applications that exhibit harsh environments, such as mining, oil and gas, chemicals, food and beverages, power, pulp and paper, pharma, and water and waste water industries.

Product Features

Reduced associated costs

Does not require any maintenance

No calibration necessary

Versatile level transmitter

Highly reliable instrument

Provides a precise measurement of any solid or liquid surface

Equipped with both dust and fog penetration capabilities

Explosion proof class 1 / division 1 (zone 1)

Extremely convenient tool for fast-pace industries

Rapid and flexible installation

Easy setup function

2-wire powered

Equipped with HART communication

Ensures rapid delivery of results in less than two weeks from order to reception

Continuous and non-contact laser measurement of any solids or liquids, as well as clear mediums

Allows this product to meet the increasing demands of process automation and inventory management in various industries

Equipped with laser level transmitters

Accessories

Dust tube

Prevents dirt or splashing liquids from contaminating the window

Cooling tube

Increases the maximum process temperature to as high as 280 °C/535 °F

Heated window

Prevents condensation on the window

Requires 4 wire power to function

Integrated ‘Through-the-Glass’ user interface

Directly configured to the unit

Rotating bracket

Precisely aims the LLT100 laser beam as necessary

Swivel flange

Provides users with a precise aiming of the LLT100 laser beam

Particularly applicable for liquid applications

Laser pointer tool

Provide users with a visual reference during alignment of the LLT100

Process Flanges

Aluminum or stainless steel universal flange

Bolt pattern fits both 2-inch ASME150 and DN50 PN 16

Maximum pressure: 2 bar (29 psi)

Hazardous area class 1 / division 1 (zone 1)

High pressure capabilities

2 in. class 150 flange

2 in. class 300 flange

DN50 PN16 flange

DN50 PN40 flange

Hazardous area class 1 / division 1 (zone 1)

Capable of forming a barrier to zone 0

Hygienic interface

Achieved using a 4-inch triclover clamp
