Mastersizer 3000+ Pro
The Smartest Way to Measure Particle Size
The Mastersizer 3000+ Pro is a mid-tier laser diffraction device for particle size analysis when a vast size range is not required. This instrument provides accurate size measurements ranging from 0.1 to 1000 microns and has a more advanced software experience with Mastersizer Xplorer and automatic dispersion options.
Image Credit:Malvern Panalytical
Features
The Mastersizer 3000+ Pro produces the finest quality data for applications that require micron-scale scaling capabilities and the sophisticated software choices of Mastersizer Xplorer.
Robust and dependable sizing performance in the range of 0.1-1000 µm, ideal for users that do not require sub-micron or millimeter scale size information.
The user-friendly software includes tools for automated measurement setup, method creation, and live data monitoring. Includes new Data Quality Guidance and SOP Architect functionality.
Various manual and automatic attachments for measuring suspensions, emulsions, and powders provide flexibility to match specific sample needs.
Smart Manager provides real-time health monitoring to save downtime and enhance the particle size experience.
Upgrade option to Mastersizer 3000+ Ultra
Mastersizer 3000+: Class leading performance with added intelligence
Specification
Source: Haydale Limited
| General | |
|---|---|
| Particle size | Suspensions, emulsions, dry powders |
| Principle | Laser light scattering |
| Analysis | Mie and Fraunhofer scattering |
| Data acquisition rate | 10 kHz |
| Typical measurement time | <10 sec |
| Dimensions (W, D, H) | 690 mm x 300 mm x 450 mm |
| Weight | 30 kg |
| Optics | |
| Red light source | Max. 4 mW He-Ne, 632.8 nm |
| Blue light source | None |
| Lens arrangement | Reverse Fourier (convergent beam) |
| Effective focal length | 300 mm |
| Detector | |
| Arrangement | Log-spaced array |
| Angular range | 0.032 - 60 degrees |
| Alignment | Automatic |
| Size | |
| Particle size | 0.1 - 1000 µm * |
| Number of size classes | 100 (user adjustable) |
| Accuracy | Better than 0.6% ** |
| Precision / Repeatability | Better than 0.5% variation * |
| Reproducibility | Better than 1% variation * |
| System compliance | |
| Laser safety | Class 1, IEC60825-1:2007 and CFR Chapter I: Sub-chapterJ: Part 1040 (CDRH) |
| Regulatory testing | RoHS and WEEE-compliant, CE / FCC-compliant. Meets requirements of the European Low Voltage Directive |
| System | |
| Power | 100/240 V, 50/60 Hz 50 W (no dispersion units connected) 200 W maximum (2 dispersion units connected) |
| Humidity | 80% maximum for temperatures up to 31 °C, decreasing linearly to 50% at 40 °C. Non condensing. |
| Operating temperature (°C) | +5 °C to +40 °C |
| Product storage temperature | -20 °C to +50 °C |
| Ingress Protection (IP) rating | IP41B |
| Patents | |
| Patents | The Mastersizer optical bench is protected by patents based on applications WO2013038161, WO2013038160 and WO2013038159. |
* Sample and sample preparation dependent** Accuracy defined for the measurement of monomodal latex standards. This specification accounts for the manufacturer’s uncertainty in the latex size. Sample and sample preparation dependent.
