Lyza 7000 FTIR Spectrometer: Cutting-Edge Molecular Analysis Tool
Anton Paar’s Lyza 7000 FTIR spectrometer can measure hundreds of solid, liquid, or gaseous samples within a single compact instrument. It is the most dependable, easy-to-use FTIR spectrometer on the market, setting new industry standards across various application areas.
The instrument’s powerful software interface automates measurement, processing, and spectral analysis. It also includes a customizable measurement report, allowing users to collate the required data in a format tailored to them.
Key Features
The Market’s Most Reliable FTIR Spectrometer
Image Credit:Anton Paar GmbH
The Lyza 7000’s consistently accurate results are based on a foundation of rigorous testing and validation.
Ongoing internal system monitoring ensures any possible issues are identified and rapidly resolved.
A smart status LED light provides users with at-a-glance progress updates.
Industry leaders have designed this FTIR spectrometer for optical analysis and quality control.
Solutions Tailored for Specific Industry Demands
Image Credit:Anton Paar GmbH
Each application package can be tailored to meet specific requirements.
The Lyza 7000’s modular cell concept can accommodate any sample type: solid, liquid, or gaseous.
The instrument is fully compatible with an array of ATR and transmission cells, opening up its potential use in hundreds of applications.
Users can meet key analytical needs without replacing the whole system.
Measuring cell exchange is simple and automatically recognized by the instrument.
Guided workflows and various valuable accessories mean users can intuitively perform measurements immediately.
An adjustable touchscreen ensures a truly intuitive user experience.
Powerful Spectral Libraries
Image Credit:Anton Paar GmbH
Spectral libraries allow an FTIR spectrometer to directly identify and verify virtually any unknown substance or sample.
Users can create a specialized library customized to specific application requirements.
A range of industry-standard libraries is available in the embedded software, including S.T.Japan, Aldrich, and IChem.
The Anton Paar factory library allows users to identify samples out-of-the-box.
Users can perform incoming goods control, batch quality control, or essential R&D tasks, quickly and easily.
Boost Efficiency with Time, Space, and Cost Optimization
Image Credit:Anton Paar GmbH
Automatic calibration is possible in mere minutes with the instrument’s internal polystyrene reference.
The AP Connect platform can effectively streamline data management.
The instrument boasts minimal bench space requirements due to its small footprint and touchscreen.
‘Eco Mode’ notably reduces energy consumption while prolonging the lifetime of core components.
Cost efficiency is assured with no compromise on performance or quality.
The Anton Paar Spectroscopy Suite: Efficiency Meets Compliance
Image Credit:Anton Paar GmbH
The AP Spectroscopy Suite software allows the Lyza 7000 to achieve full compliance in regulated environments.
The Suite meets key standards for seamless regulatory compliance, including 21 CFR Part 11 and EU GMP Vol. 4 Annex 11.
Data integrity remains error-free, ensuring lifetime compliance in regulated environments.
The Suite has been specifically designed to prevent errors before they occur, limiting the need for corrective actions based on assessments of audit trails.
The Suite streamlines daily measurements by utilizing predefined workflows and settings, effectively removing complex spectroscopy tasks.
Data is securely stored in an SQL database, ensuring no deletions can occur.
The Suite facilitates accurate data submission, review, and approval, significantly streamlining necessary compliance processes.
Technical Specifications
Source:Anton Paar GmbH
| . | . |
|---|---|
| Detector | Pyroelectric DLaTGS detector |
| Optics | Hermetically sealed aluminum casing with gold-coated mirrors, KBr windows and beamsplitter |
| Signal-to-noise ratio | 55,000:1 (1 min, 8 cm-1, 1,900 cm-1 to 2,250 cm-1) |
| Spectral range | 350 cm-1 - 7,500 cm-1 |
| Spectral resolution | 1.4 cm-1 - 16 cm-1 |
| Wavenumber accuracy | <0.05 cm-1 @ 900 cm-1 - 3,000 cm-1 |
| Measurement time | <30 seconds |
| Laser type | Single mode Vertical Cavity Surface Emitting Laser (VCSEL) |
| Laser class | Class 1, enclosed hermetically |
| IR Source | SiC composite |
| Interferometer | Permanently aligned cube corner interferometer |
| Desiccant | Molecular sieve with color indicator, user-replaceable |
| Operating temperature range | 10 °C - 30 °C (non-condensing) |
| Instrument dimensions | 365 mm x 315 mm x 382 mm (D x W x H) |
| Cell compartment width | 152 mm |
| Weight | 12.8 kg |
| Power supply | DC 24V, 40 W |
| Communication interfaces | 4 x USB 2.0 / CAN / Ethernet / Wi-Fi* |
| Data export formats | .csv, .pdf, .spc |
| Data management | AP Connect |
| Display | 10.1”, PCAP-Touchscreen, multi-touch |
| Controls | Touchscreen, optional keyboard, mouse, and barcode reader |
| Internal storage | 32 GB |
| Spectral libraries | Factory library, user-built, third-party options |
| Security | User roles with customizable permissions, user password logins |
| Regulatory Compliance | 21 CFR Part 11 including installation, operation qualification and performance qualification (DQ /IQ/OQ/PQ)** |
*via external Wi-Fi stick**only available in combination with Anton Paar Spectrocopy Suite
