Lt-C/M1630B: For Reliable Automation Imaging

Embedded systems can capture images in a variety of lighting conditions, thanks to the Lt-C/M1630B camera’s high dynamic range and the IMX430’s High Conversion Gain feature.

This is extremely advantageous in factory automation applications such as quality control, where cameras must be engineered in tight design spaces. Moreover, with a high frame rate, production can operate at greater speeds without any worry about the reliability of the image quality.

Highlights of the Teledyne Lumenera Lt-C/M1630b Board Level Camera

Selectable 8 or 12-bit pixel data

High-Speed USB 3.1 Gen 1 interface for fast image delivery and simplified connectivity

Compact form factor measuring 40 mm x 40 mm x 17 mm

Locking industrial micro USB on the side for power and control

Multiple data rates are supported, each optimized for the lowest noise performance

High Conversion Gain (HCG) allows the camera to capture clearer images in low-light environments with reduced read-noise

Region of Interest (ROI) option to provide higher frame rates

Color or monochrome Sony^® Pregius^™ IMX430 global shutter CMOS sensor with 1/1.7” optical format

2.0-megapixel camera with fast frame rates of 86 fps at full resolution (1632 x 1248)

For additional information, please see theLt Series USB Cameras User Manual

About Sony Pregius Gen 3 Global Shutter CMOS Camera Technology

The Teledyne Lumenera Lt Series Board Level Cameras benefit from a new level of dynamic range thanks to Sony Pregius Gen 3 sensors.

Designed with larger pixel sizes and capable of large full well capacities, the Sony Pregius Gen 3 sensors are able to capture greaterdetail in low light conditions.

These sensors are ideal for use in outdoor imaging or with fluctuating brightness levels, thanks to the High Conversion Gain feature. This unique offering means that the camera is ableto capture clearer images by capturing more light without introducing high levels of noise.

Ordering Options

Lt-M1630B — 2.0 MP Monochrome USB3 Board Level Camera

Lt-C1630B — 2.0 MP Color USB3 Board Level Camera

La303ML — USB 3.1 Cable A-Male to Micro-B male Locking (3 m/9.75 ft)

Software Platform Options

USB3 Vision-compliant SDK

Teledyne Lumenera Camera SDK (Windows and LINUX)

Key Applications

Portable/OEM Devices

Outdoor imaging

Aerial imaging

Precision agriculture

Life sciences

Intelligent Traffic Systems (ITS)

Industrial inspection solutions

Technical Specifications

Camera Specifications

Source: Teledyne Lumenera
