KELLENBERGER® 10
The KELLENBERGER® 10 from Hardinge is a standardized machine with the potential to offer an unrivaled price-performance ratio. The machine integrates proven components updated recently based on the latest technology.
The machine also features an intuitive programming surface, thus creating a highly capable base that can be customized easily by a wide array of optional equipment base on the requirements of the customer.
Features
The standard machine for experts and beginners alike in the precision grinding field
Price-performance ratio — Unparalleled value for function and performance in the market
Engineered for workpieces smaller than Ø400 mm x 1000 mm
BLUE Solution Software on a touch display measuring 19″
Between tips up to 100 kg, flying up to 80 kg
Guided programming and retooling, can be done even by novice operators
Hardinge KELLENBERGER® 10 (English)
Video Credit: Hardinge Inc.
Hardinge Kellenberger 10 (German)
Video Credit: Hardinge Inc.
Technical Data
Source: Hardinge Inc.
| . | . | . |
|---|---|---|
| Characteristics | ||
| Distance between centres | mm | 1000 |
| Centre height | mm | 200 |
| Weight of workpiece between centres | kg | up to 100 |
| Load on chucked work | Nm | up to 100 |
| Mains voltage required | V | 400 / 460 |
| Power consumption depending on equipment | A | up to 40 |
| Space required / length x width | mm | 2.7 x 2.2 / 3.5 x 2.2 |
| Total weight | kg | 4.000 |
| Table/Slide Z-axis | ||
| Travel | mm | 1.150 |
| Rapid traverse speed | m/min | up to 20 |
| Resolution | mm | 0.00001 |
| Wheelslide X-axis | ||
| Travel | mm | 365 |
| Rapid traverse speed | m/min | up to 10 |
| Resolution | mm | 0.00001 |
| Swivel devices | ||
| Swiveling range | degree | 240 |
| Automatic indexing of resolution | degree | 1 |
| Wheelhead | ||
| Water-cooled drive motor | KW | 7.5 |
| Performance peripheral speed | m/s | up to 50 |
| Grinding wheel dimensions | mm | up to Ø500x80 |
| Internal grinding device | ||
| Bore for spindles up to | mm | 150 |
| Power, HF spindles | KW | up to 7.5 |
| Rotation speed | rpm | up to 60.000 |
| Workhead | ||
| Rotation spindle speed | rpm | 1 - 1,000 |
| Interface | ISO 702-1, Size 5/MT5 | |
| Roundness accuracy in chucked work | μm | 0.4 (optional 0.2) |
| Tailstock | ||
| Internal taper | MT4 | |
| Retraction of sleeve | mm | 49 |
| Micro-adjustment | μm / Ø | ±60 |
All data are subject to change without notice
