Integrated Analyzer System Solution: Advance Optima AO2000
The Advance Optima series features a modular system design and the broadest variety of analytical technologies, from specialized process photometers to in-line laser measurement. Ethernet networks provide centralized and remote operation. The series is designed for usage in hazardous environments and with flammable sample gases.
ABB Ability™–Maintenance Made Easy with Scalable Digital Solutions
Dynamic QR Codes offer quick and simple access to all pertinent diagnostic data for quicker troubleshooting and repairs.
Remote Assistance solution provides professional on-demand support, delivering remote diagnostic and assistance for the analyzers.
Condition Monitoring performs scheduled remote product health checks and gives accurate early warnings for recommended maintenance activities.
Genix Datalyzer is a cloud-based analyzer and fleet health monitoring tool
Overview
The Advance Optima process gas analyzers' modular design provides long-term investment security. Analyzer modules can be flexibly coupled to create custom solutions, and they can always be updated or expanded to include new functionality. Remote modules can be conveniently added and managed centrally.
The benefits that Advance Optima provides to users include:
One central unit and up to fouranalyzer modules:
With common control
With a common connection technology
In a common system housing
All analyzers use high-performance measurement technology:
Photometers
In-Situ Laser Analyzer
Oxygen Analyzer with new microwing technology
Oxygen Analyzers
Trace Oxygen Analyzer
Thermal Conductivity Analyzers
FID Analyzers
Multiple analyzer systems:
Up to four analyzer modules
With up to six sample components
Extensive automatic calibration:
With air or integral calibration cells
No need for test gas cylinders
The self-monitoring mechanism informs when maintenance is necessary
Hazardous area authorized models in conformity with international regulations, such as:
ATEX
EAC
CSA
Hazardous area version for FID, AO2040-Fidas24 Ex
For measuring flammable gases in Zone 1, 2, 21, 22
“Safety Concept” to measure flammable gases in Zone 2
Offers Ethernet TCP/IP interfaces, OPC server, PROFIBUS, and Modbus interfaces
Data
Advance Optima Series–Design Variations
Source: ABB Measurement & Analytics, Americas
| AO2020 | AO2040 | AO2040-Fidas Ex |
|---|---|---|
 19" rack-mounted version for controller, display/keypad, power supply, and one analyzer module. Additional housings for external analyzer modules are possible |
 Wall mounted versionAdditional housings for external analyzer modules are possible |
 A special wall-mounted version is needed for the hazardous area installation of the FID analyzer (stand-alone). |
Advance Optima Series–General Data
Source: ABB Measurement & Analytics, Americas
| Size AO2020 | Size AO2040 | Size AO2040-Fidas24 Ex |
|---|---|---|
| 483 mm W x 412(597)* mm D x 177 mm H*values with connectionbox in brackets | 444 mm W x 199 mm D x 412(597)* H*values with connectionbox in brackets | 444 (567)* mm W x 199 mm D x 412(601)* mm H*values with connectionbox and purge controller in brackets |
| Housing protection | Housing protection | Housing protection |
| IP 20IP 54 with connection boxIP 65 without power supply/display/control unit | IP 20IP 54 with connection boxIP 65 without power supply/display/control unit | IP 65 |
| Power supply | Power supply | Power supply |
| 100…240 VAC, 2,2 A max | 100…240 VAC, 2,2 A max | 110 … 230 VAC, 2 A max. |
Analyzer Modules
The AO2000 series offers the broadest selection of analyzer modules. Up to four modules can be combined to create customized solutions.
All analyzers employ high-performance measurement technology and a streamlined calibration procedure that does not need test gas bottles.
Thermal Conductivity Analyzers
FID Analyzers
NDIR and UV Photometers
In-Situ Laser Module
Oxygen Analyzers
Trace Oxygen Analyzer
Source: ABB Measurement & Analytics, Americas
| Type | Name | Sample Gas (Examples) | Application | |
|---|---|---|---|---|
| Photometers | ||||
| Infrared Photometer | Uras26 | CO, CO2, NO, SO2, N2O, CH4, C3H8, C2H4, ..(max. 4) | Emission, firing, landfill, gas production, burners, fermenters, process monitoring | |
| Process Photometer | Limas21 UV | NO, SO2, NO2, H2S, Cl2, COS, ...(max. 3) | Production and processing of Cl2, cellulose, viscose rayon, plastic prod. | |
| Process Photometer | Limas21 HW | NO, NO2, NH3, ...(max. 3) | Diesel engine, managing DeNOx, catalyzer | |
| In-Situ Laser | ||||
| TDLS | LS25 | O2, CO, CH4, NH3, H2O, CO2, HCL, H2S, HCN, HF, ...(max. 2) | Combustion optimization, DeNOx, process measurement and -optimizatione.g. in energy-, metal-, chemical-, petrochemical-, glass-, cement- and paper-industry | |
| Oxygen Analyzer | ||||
| Paramagnetic | Magnos28 | O2 | CEMs, Air fractionating, biochemical plants, purity,with microwing technology | |
| Thermo-magnetic | Magnos27 | O2 | Flue gas analysis, roasting gas, cement flue gas | |
| Thermal Conductivity | ||||
| Silicon sensor | Caldos27 | Ar in O2, H2in Ar, H2in N2/Air, ... | Hydrogen purity, turbo generator, inert gas monitoring, UEL/LEL monitoring | |
| Glass cell | Caldos25 | H2in Cl2, SO2in N2/Air, H2in N2/Air, ... | Chlorine production, sulfur dioxide in smelter-off gas, ammonia dissociation | |
| Flame Ionization | ||||
| FID Detector | Fidas24 | Hydrocarbons | Volatile organic compounds, emission monitoring, automotive industries, ambient air, process control | |
Service
ABB provides a comprehensive set of services to help users and their processes, including:
Product commissioning
Maintenance and field services
Repairs
Spare parts services
My Measurement Assistant
Training
Digital
Digital and Advanced Service Products
ABB Ability™ provides scalable digital solutions for analyzers and systems, including:
Dynamic QR Code - Allows for quick transmission of all important diagnostic information for quicker troubleshooting and repair
Remote Assistance: For skilled on-demand service offering remote diagnostics and help for analyzers
Condition Monitoring: Offers scheduled remote product health checks and delivers trustworthy early warnings for necessary maintenance actions
Genix Datalyzer: Cloud-based analyzer fleet health monitoring solution
Discover how ABB's Scalable Digital solutions can assist users in making proactiveand informed decisions on the health of the analyzer, as well as its maintenance and repair.
