Integrated Accelerometer for Vibration & Shock Measurement

The Model 966 Piezoelectric Accelerometer from Columbia Research Laboratories has been particularly developed for the measurement of high frequency, intermediate to high-level shockand vibration. It integrates a hybrid electronic assembly inside a rough, welded, double-wall stainless steel body to improve its functioning in humid and filthy surroundings.

The double-wall and electrically isolated construction of the sensor offer extra isolation from metallic structures, which helps in obtaining precise, wideband shockand vibration data uninterrupted by electrical ground loop currents.

The sensor module has been bonded into the outer stainless-steel body with a high temperature and glass-filled polymer insulator. Low impedance output of 100 ohms or less enables functioning straight into standard readout equipment in the absence of auxiliary signal conditioning.

Also, it has the potential to drive up to 500 ft of shielded cable. Users can consult the factory for customized versions of this sensor.

Image Credit: Columbia Research Laboratories

Vibration and shock

Low impedance output

Sensitivity is 10 mV/g

Sealed hermetically

Isolation is done electrically

Low base strain sensitivity

Specifications

Source: Columbia Research Laboratories

Notes:

¹ At +75 Deg F, 10 g Peak, 100 Hz; Power Supply 2 To 10 mA DC Constant Current with 18 To 30 VDC Min. Compliance² Referenced to Sensitivity @ 100 Hz.³ Unit is Hermetic Sealed.

Accessories Supplied

(1) Comes with miniature cable assembly, LNHT-3 Ft.

(1) Mounting Stud, St. Stl measures around 10-32 x 0.380"L

(1) Standard calibration data possible

(1) Hardwood storage case is available

(1) Provided with the Certificate of Calibration Traceable to N.I.S.T.
