IEM 10 and IEM 10+ from Inovenso

IEM 10

The IEM 10 from Inovenso has the following features:

Auto stage: X, Y, T Axis

Click and move stage control

Magnification up to x 100,000

High definition image : 5120 X 3840 Pixel

Auto function: filament memory, focus, brightness, contrast

Specifications

Magnification: x20 ^~ x100,000 (Efficient: ^~x50,000)

Acc Voltage: 1 ^~ 30 kV (1 kV increments)

Electron Gun: Tungsten Filament (W)

Detector: SE Detector

Stage: Auto Stage (X: 35 mm,Y: 35 mm,T: 0 to 45^o) Manual Stage (Z: 5 to 50 mm)

Image Shift: X, Y, R (Rotation)

Operating System: Microsoft Windows 7

Dimensions (mm): 400(W) x 600(L) x 550(H)

Dimensions (inch): 15,74(W) x 23,62(L) x 21,65(H)

Weight: 85(kgs) - 187 (lbs)

Stage Position

Users can effortlessly locate the sample on the stage.

Click and Move

By applying the auto stage, stage is controlled easily with a mouse click.

Auto Focus and Fine Focus

Auto focus function allows easy operation and clearer images can be obtained even at the greater magnifications.

Filament Memory

Filament’s saturation point is automatically stored and then activated.

IEM 10+

The IEM 10+ from Inovenso has the following features:

Auto stage: X, Y, T Axis

Click and move stage control

Magnification up to x 100,000

High definition image: 5120 X 3840 Pixel

Thermo EDS Detector: 133 eV at Mn, B(5) ^~ U(92)

Auto function: filament memory, focus, brightness, contrast

Specifications

Electron Gun: Tungsten Filament (W)

Detector: SE and EDS Detectors

Stage: Auto Stage (X: 35 mm,Y: 35 mm,T: 0 to 45^o) Manual Stage (Z: 5 to 50 mm)

Magnification: x20 ^~ x100,000 (Efficient: ^~x50,000)

Acc Voltage: 1 ^~ 30 kV (1 kV increments)

Image Shift: X, Y, R (Rotation)

Operating System: Microsoft Windows 7

Weight: 95(kgs) - 210(lbs)

Dimensions (mm): 400(W) x 600(L) x 550(H)

Dimensions (inch): 15,74(W) x 23,62(L) x 21,65(H)

Rapid EDS Analysis

Point and shoot analysis with NORAN System 7 software uses standardless quantitative analysis to allow rapid identification of different regions within a material.

Extracted Linescans

Extracted Area Analysis

EDS Analysis with NORAN

System 7 Spectral Imaging

The UltraDry Compact EDS detector provides exceptional elemental mapping within just a few minutes. With Spectral Imaging, where a complete EDS spectrum is stored at every pixel, samples can be analyzed after they are removed from the microscope. NORAN System 7 tools offer a number of analytical methods for the best results.
