High Vacuum Components for Clean Energy

Kyocera's ultra-high vacuum metalized components are used in sealed containers (chambers) to manufacture and conduct scientific experiments in a variety of settings, including vacuum, liquid, and gas. End use applications include particle accelerators, semiconductor processing equipment, and more.

These components usually have a hermetically sealed structurebetween the conductive and insulating portions. Kyocera uses Fine Ceramics for the insulating component. The vacuum component is welded to the flange and then fittedin a chamber with an O ring and a gasket to ensure hermeticity.

Source: Kyocera International Inc

Kyocera Fine Ceramics Components for Clean Energy

Type	Overview
VacuumFeedthroughs	They are also called hermetic seals, feedthroughs, or vacuum current feedthroughs. Attached to sealed containers for taking in and putting out signals or current/voltage
ElectricalInsulator Parts	Used for electrical insulation of piping connections
SapphireWindows	Optical windows featuring single-crystal sapphire to observe the inside of the chamber

Image of component constitution for conventional vacuum feedthrough. Image Credit:Kyocera International, Inc.
