High-End Spectroradiometer Performance with the Neo

Neo Spectroradiometer

VIS 370–850 nm

The Neo VIS spectroradiometer provides high-end performance, remarkable ease of use, and resilience. This radiometer is provided with a lens, cosine corrector, and sturdy industrial connector and fiber for measurements in the visible wavelength region.

UV-NIR 250–1100 nm

The Neo UV-NIR spectroradiometer is ideal for various analytical tasks, includingabsorbance, transmission, LED and solid-state lighting measurements.

Neo VIS and UV-NIR versions can be equipped with a lens, a cosine corrector, and a strong industrial connector and fiber.

Image Credit: Admesy

Highest Accuracy

The best optical performance is ensured by a well-thought-out optical and mechanical design. The Neo series is distinguished by exceptional linearity, greatest wavelength accuracy, and excellent low-level performance.

Image Credit: Admesy

Robust Coupler

A one-of-a-kind industrial-grade connector with a strong fiber ensures dependability even in harsh situations. Choose from various lens and accessory options, including standard SMA and FC/PC connectors.

Image Credit: Admesy

Fast Measurements

The high optical throughput and low-noise sensor enable the fastest measurement speeds, contributing to the shortest takt times in any manufacturing process.

Image Credit: Admesy

Highlights

Accuracy and precision in performance: linearity, wavelength, and dark current calibration

Better connectivity

User friendly

Easy to integrate into systems (SDK)

Modular bench options

Robust coupler, optional SMA, SMA-notched, and FC/PC connectors

Calibration manager

Attractive price point

Low calibration maintenance cost

Image Credit: Admesy

Measurement Kits

The Neo Series is currently available in four configurations. Custom configurations are available on request.

Table 1. Source: Admesy

	CIE 127	Cosine Corrector	Cuvette	Transmission
CIE 127 conformant Integrating Sphere
Industrial Strength Cosine Corrector
Cuvette Holder
Industrial Strength Collimating Lens				2
Industrial Strength Fiber			2	2
Crius LED Light Source
LED positioning stage
Neo Software Suite
Traceable Wavelength Calibration for			Fiber	Fiber
Irradiance PTB Traceable Calibration	Fiber	Fiber / Direct Coupling
