Handheld Optical Cmm 3D Scanner: Metrascan 3D

Unexpected costs, production and part approval delays from non-conformities are no longer an issue when using Creaform’s portable optical CMM 3D scanner, the MetraSCAN 3D. Help operators better manage processes and respond faster to the industry’s increasing quality control (QC) requirements—all without compromising the manufacturing throughput. Optical metrology provides measurement accuracy that is insensitive to the instabilities of the environment, making the MetraSCAN 3D optical CMM the prime choice for shop-floor quality control metrology.

With its extendable measuring volume, incredible speed, shop-floor accuracy and impressive capabilities on challenging materials, the MetraSCAN 3D represents the most complete metrology-grade 3D scanner on the market.

New Features

12X faster with seven laser crosses

1.5X more accurate

Any type of material can be scanned, regardless of whether it is black, multi-colored, or shiny surface

25% lighter

Greater volume of 16.6 m³ (586 ft³)

Multi-function buttons for more effortless interaction with the software

Robust design for shop-floor hardware reliability

Application

The MetraSCAN 3D enables highly accurate measurements directly on the production line.

Inspection

First article inspection

Part-to-CAD analysis

Supplier product quality inspection

Evaluation of conformity of manufactured parts against originals

Evaluation of conformity of 3D models against production tooling or original parts

Tooling certification

Alignment

Reverse Engineering

3D modeling

3D scan-to-CAD

Finite element analysis (FEA)

Tooling and jig development

Maintenance, repair, and overhaul (MRO)

The MetraSCAN 3D is Compatible with Other Leading Engineering Software

InnovMetric Software - PolyWorks

3D Systems - Geomagic Solutions

Delcam - PowerINSPECT

Dassault Systèmes - CATIA V5, SOLIDWORKS

Metrologic Group - Metrolog X4 and V5

BuildIT Software and Solutions - BuildIT

New River Kinematic - SpatialAnalyzer

PTC - Pro/ENGINEER

Verisurf - VerisurfMeasure

Siemens - NX and Solid Edge

Autodesk - Inventor, 3ds Max, Alias, Softimage, and Maya

Industries

Automotive/transport

Aerospace

Manufacturing

Consumer products

Power generation

Heavy industries

Research and education
