Gas Monitor - ULTIMA® X5000

The ULTIMA^® X5000 Gas Monitor from MSA is the future of gas detection for oxygen, toxic and combustible gases. MSA XCell^® gas sensors with TruCal^® technology delivers calibration cycles up to 18 months (local calibration respected). The gas transmitter's advanced, multi-lingual OLED display is simple to read and the innovative touch-screen interface makes it easy to navigate.

Highlights

An industry first, a touch-button interface for an intuitive user experience and tool-free operation

New design with an Organic LED (OLED) display and bright status LEDs for extreme visibility

TruCal technology dynamically monitors the sensor integrity and compensates for environmental influences that cause standard electrochemical sensors to drift

Reduces downtime

Automatically self-checks 4x/day

Three year warranty on XCell sensors

SafeSwap enables safe and fast replacement of gas sensors without switching off the instrument

Dual sensor capability doubles the sensing power with half of the footprint of a single gas transmitter

Bluetooth wireless technology allows mobile device to serve as an HMI screen and controller. The X/S Connect App is programmed with high security standards and offers real-time information to the mobile device of the user

Reduce set up time by at least 50%

Check status and get alerts up to 75 ft. (23 m) away

Identical footprint and wiring as the ULTIMA X series simplifies retrofits using the present conduit and wiring as well as an integral mounting bracket

Markets: Industrial, oil and gas, utilities

Applications: Building protection, confined space, oxygen detection, combustible detection, food processes, perimeter monitoring, toxic detection

Options

Ordering Options

ATO configurator

Accessories

Mounting bracket

HART port

Duct mount kit

Sun shield

Remote junction box

Housing entries M25 or ¾”NPT

Approvals

US Divisions

Class I Div 1 Groups A-D, T5, Type 4X, IP66 Class II Div 1 Groups E-G, T6; Class III

US Zones

Class I Zone 1 AEx db IIC T5 GbClass II Zone 21 AEx tb IIIC T85 °C Db Global ZonesEx db IIC T5 GbEx tb IIIC T85 °C Db

CSA, ATEX, IECEx, CE Marking.Complies with C22.2 No. 152, FM 6320, IEC/EN: EN 60079-29-1, ANSI/ISA 12.13.01.Suitable for SIL 2
