CAV® 4.2 | Dual-Bath, Two-Tube, Benchtop Kinematic Viscometer

The CANNON®CAV 4.2is a dual-bath, completely automated, benchtop viscometer with a 28 position (two 14-position carousels) sample handlerfor unattended D445 processing. Each of the two tubes (one per bath) spans a 100-fold viscosity range from 15 °C to 150 °C(with available options) at values ranging from0.5 to 10000 mm²/s (cSt).

Features and Benefits

D445 Precision in a Modern, Dependable Design

A trusted CANNON viscometer platform offers reliability anddependable support

Two independent baths allow for testing at two temperatures at the same time

Two removable, 14-position sample handlers provide dependable, unattended processing of up to 24 determinations each hour

Automation replaces labor-intensive manual testing and lowers operator-to-operator inconsistency

Multi-colored bath lights, visible from across the lab, provide an indication of operational status

Temperature range is40 to 100 °C (15 to 150 °C with bath options)

Viscosity range is0.5 to 10000 mm²/s (cSt) in 100-fold increments* (spanning the range of fiveindividual manual viscometers)

Compact and Self-Contained with Flexible Configuration

Included VISCPRO^®softwareenables user-defined test methods and the management and control of up to four instruments from a single PC

Optional, eco-friendly Peltier cooling entails no external refrigeration

Easy, out-of-the-box installation

View, print, save, and export user-configurable reports

An onboard computer enables the execution of preprogrammed test settings without the use of an external PC

Reduced Consumable Costs

Automation ofvial washing and drying allows for reuse andreducesvial consumption

When compared to larger predecessor tubes, next-generation Atlantic-style tubes lower solvent usage and disposal expenses by 50%

Simplified Maintenance and Test Versatility

Several differenttesting methods can be performed in the same sample tray

Includes standarddual-solvent input

Operators can replace tubes in minutes, reducing the need for related support calls

A modular bath design provides easy access for maintenance

High throughput and selectivezone heating of individual samples from 40to 100 °C

Common Applications

Formulated oil analysis

Hydraulic oil analysis

Additive analysis

Marine fuel testing

Base stock analysis

Light and heavy fuel testing

Waxes/paraffin testing

Crude oil testing

Glycols

*The test temperature and sample type may limit some higher viscosity measurements. Ubbelohde-style tubes (for volatile compounds that are not pure solvents and high melt waxes) are also offered in 100-fold increments and rapid run 10-fold increments from 0.5 to 10,000 mm²/s (cSt).
