Bruker Optics - SIGIS 2 Remote Sensing

The SIGIS 2 allows identification, quantification, and visualization of potentially hazardous gas clouds from long distances. SIGIS 2 (Scanning Infrared Gas Imaging System) is a scanning imaging remote sensing system based on the combination of an infrared spectrometer with a single detector element and a scanner system.

Simple Operation

The image of the scene is displayed by a camera (video or infrared). In the basic mode of operation the operator chooses an area to examine by drawing a frame in the video image. Then the scanning mirror sequentially scans the scene and the incoming infrared radiation is analyzed in real time. The results are visualized by the video image, overlaid by an image of the potentially hazardous gas cloud. This direct display of the cloud image in the video image allows simple assessment of the position and the size of the cloud. The combination of a rotating head with a scanning mirror allows 360 degree observation and imaging.

Feature Highlights

Long range detection (integrated telescope)

Ultra low noise

Highest optical throughput

Lowest detection limits

Unique system that combines performance of single detector FTIR with imaging

Automatic real-time identification

Compensation of atmospheric gases and interferents

Large spectral library (TICs, CWA optional)

Image overlay allows simple interpretation

Robust (deployed by emergency response forces since 2006)

Automatic 360 degree surveillance and user-defined operation

Video and infrared cameras for day and night use

Complete documentation of measurement

Scene image, spectra, compounds, position, time etc.

Automatic transmission of data to server

Transmission to command center or external experts

Post analysis by external experts possible
