Blackfly S Board Level Camera: Full-Featured, High Performance for Embedded Systems
The Blackfly® S camera exploits the industry’s most cutting-edge sensors in an ice-cube form factor. Packed with robust features, the camera allows users to effortlessly create their preferred precise images and speed up their application development.
This includes both accurate manual control and automatic control across on-camera pre-processing and image capture. On-camera features, such as full compatibility with well-known third-party software that supports GigE Vision, as well as IEEE1588 clock synchronization, provides system designers with the required tools to rapidly design novel solutions. The Blackfly® S camera is available in USB3, GigE, board-leveland cased models.
The Exact Images Required by Users
The Blackfly® S camera offers a choice of polarization, CMOS global shutterand high-sensitivity BSI sensors. True-to-life color is ensured by color transformation tools. Accurate manual control and sophisticated auto-algorithms are also included.
Develop Once, Deploy Anywhere
The Blackfly® S camera supports a variety of host system hardware architectures and operating systems. Users can effortlessly switch to board-level models for built-in systems. Streamlined product iteration with reliable form-factor is available across different sensor sizes.
Accelerate Application Development
The Blackfly® S camera can be used with third-party hardware and software. Robust on-camera features minimize code-writing tasks. Custom applications can be rapidly built with descriptive API logging and a rich-sample code.
FLIR Blackfly S Family: Develop Once, Deploy Everywhere
Video Credit: FLIR Systems
Specifications
Source:FLIR Systems
| Overview | |
|---|---|
| ADC | 8-bit, 10-bit, 12-bit |
| Chroma | Color |
| Frame Rate | 291 |
| Lens Mount | CS-mount |
| Megapixels | 0.4 |
| Part Number | BFS-PGE-04S2C-CS |
| Pixel Size | 6.9 |
| Readout Method | Global shutter |
| Required Accessories | Lens, Cable, Host Adapter (GigE), Tripod Mount Adapter (ACC-01-0003) |
| Resolution | 720 × 540 |
| Sensor Format | 1/2.9" |
| Sensor Name | Sony IMX287 |
| Sensor Type | CMOS |
| Compliance and Certifications | |
| Compliance | CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099. |
| Machine Vision Standard | GigE Vision v1.2 |
| Warranty | 3 years |
| Environmental | |
| Operating Humidity | 20 to 80% (no condensation) |
| Operating Temperature | 0° to 50°C |
| Storage Humidity | 30 to 95% (no condensation) |
| Storage Temperature | -30° to 60°C |
| Features | |
| Acquisition Modes | Continuous Single Frame Multi Frame |
| Exposure Range | 4 µs to 30 seconds |
| Flash Memory | 6 MB non-volatile memory |
| Gain Range | 0 db to 47 dB |
| Image Buffer | 240 MB |
| Image Processing | Color correction matri×, gamma, lookup table, saturation and sharpness |
| Partial Image Modes | Pixel binning, decimation, ROI |
| User Sets | 2 user configuration sets for custom camera settings |
| Performance | |
| Absolute Sensitivity Threshold (y) | 7.39 |
| Dynamic Range dB | 74.27 |
| Quantum Efficiency Blue | 48.7 (460 nm) |
| Quantum Efficiency Green | 57.43 (530 nm) |
| Quantum Efficiency Red | 45.6 (625 nm) |
| Saturation Capacity (e-) | 21947 |
| Temporal Dark Noise (e-) | 3.74 |
| Physical | |
| Auxiliary Output | 3.3 V, 120 mA maximum |
| Dimensions [W x H x L] | 29 mm × 29 mm × 30 mm |
| Interface | GigE PoE |
| Mass | 36 grams |
| Non-isolated I/O Ports | 1 bi-directional, 1 input |
| Opto-isolated I/O Ports | 1 input, 1 output |
| Power | |
| Power Consumption [Maximum] | 3 W (2.8 W nominal) |
| Power Requirements | Power over Ethernet (PoE), or 12 V nominal (8 - 24 V) via GPIO |
| Recommended System Configuration | |
| CPU | 3.1 GHz or equivalent CPU |
| Hard Drive | 200 MB hard drive space |
| Operating System | Windows or Linux (32–bit or 64–bit) |
| Port | Gigabit Ethernet Port |
| Power Sourcing Equipment | IEEE802.3af-2003 PoE Interface Card / Injector/ Switch or Camera Power Supply (12 V 1.5 A, 6–pin Hirose) |
| RAM | 2 GB RAM or more |
Accessories
Cables
GigE cable
GigE locking cable
GPIO Cables
Hirose HR10 (6 Pin) GPIO cable
Lenses
Computar A4Z2812CS-MPIR, 2.8- to 10-mm, 1/2.7", CS mount lens
Fujinon 6-mm 1/2″ C mount lens
Fujinon 25-mm 2/3″ C mount lens
Tamron 8-mm 1/1.8″ C mount lens
Tamron 16-mm 2/3″ C mount lens
Tamron 16-mm 1/1.8″ C mount lens
Tamron 25-mm 2/3″ C mount lens
Host Adapters
Ethernet Network Interface Card
Power Supplies
Includes 12 V power supply with a 6-pin HR10 connector
Optical Mounts
CS to C Mount 5-mm spacer adapter
Tripod Adapters
Tripod adapter for 39-mm Blackfly® S Models
Tripod adapter for BFS (30 mm), BFLY, CMLN, CM3, FFMV, FL2, FL3 and FMVU
Connectors
Hirose HR10 Circular GPIO connector
