72DL PLUS™ Ultrasonic Thickness Gauge

The 72DL PLUS ultrasonic thickness gauge (72DLP™ gauge) is a user-friendly instrument that provides accurate and high-speed precision thickness measurements. With a low minimum thickness capability, quick scanning, and sophisticated algorithms, users can confidently measure the thickness of ultra-thin layers and other challenging materials in manufacturing.

The 72DLP thickness gauge comes in two models—standard frequency and high frequency—to suit various precision thickness applications. The high-frequency model can measure ultra-thin materials, such as multilayer paint, plastics, metals, and coatings.

With the Multilayer Measurement feature, the gauge can display the thickness of up to six separate layers simultaneously. Every 72DLP model has the capabilities to measure thickness quickly and accurately:

Excellent signal-to-noise ratio thanks to digital filters, making it possible to measure noisy materials' thicknesses (such as fiberglass) with accuracy

Easy-to-use and high-quality touch screen can be viewed from various angles

PC interface application provides data creation, management, sharing, and analysis tools to empower data-driven decisions on the production floor and help maintain consistent product quality

72DLP Key Benefits

Confidently Control the Thickness Inspection Process

Smart tools simplify the process of taking precision ultrasonic thickness measurements, streamlining everything from application setup to performing and evaluating inspections quickly and confidently.

Large, clear display: View thickness measurements on a 7-inch high-resolution WVGA touchscreen

Multiple measurement layouts:Obtain accurate views of thickness changes using A-scan, B-scan, A/B-scan, trend, and zoom measurement layouts

Inspection guidance:The interactive part map featuring thickness measurement locations (TMLs) provides an overview of the inspection status, enabling users to do their jobfaster and with confidence

Data management and analytics: Internal data logging and PC interface application expedite the gathering and evaluation of inspection data

Connected: Wi-Fi^® and Bluetooth^®capabilities are supported for Industry 4.0 practices

Simple application setup: Create custom applications that reduce the time it takes to set up the device for regular thickness inspections

Intuitive User Interface with an Easy-to-View, Large Screen

Full-color touch screen measuring 177.8 mm (7 in.) provides access to the setup and measurement layouts

Excellent visibility with a wide viewing angle in most ambient conditions

Easily adjust the settings to suit specific needs thanks to guided configuration

Precision Ultrasonic Thickness Gauge Built for Industrial Environments

Designed to withstand dust and moisture (designed to IP65)

MIL-STD-810G drop tested to reduce the need for repairs in case of drops or falls

Wide operational temperature range of –10 °C to 50 °C (14 °F to 122 °F) for accurate measurements in cold or hot environments

Weighs 2.1 kg (4.6 lb), making it portable for the production floor

Simple-to-use adjustment knob, key buttons, and touch screen

Suitable for use on a work surface, in both indoor and outdoor environments, and with a four-point chest harness or shoulder strap

Long battery life of up to eight continuous hours

Measure the Thickness of Up to 6 Layers for Multilayer Coatings, Paint, Plastics, and Other Materials

The Multilayer Measurement feature enables multilayer thickness measurements of up to six layers. Easily access the measurement settings for each layer—including material, velocity, target thickness ranges, and alarm thresholds—through the configuration workflow and touch-screen controls.
